SNW-WX-400*2 High Speed Double Lines Star Sealing And Flat Bag Making Machine
Performance and Characteristics
1. Computer automatic control, automatic counting and set counting alarm, high efficiency, saving manpower and time;
2. From film rolling to finished bag, it is fully automatic and one-time;
3. Domestic servo motor has fixed length, photoelectric tracking, accurate and stable, and photoelectric control is adopted for feeding;
4. Adopt hot cutting device and intelligent temperature control system to make the bag mouth sealed firmly and smoothly;
5. The main engine adopts frequency converter to control speed regulation;
6. Rewinding is controlled by PLC;
7. Discharging is controlled by frequency converter;
Main Technical Parameters
项目Items | 参数Parameter |
制袋宽度Bag making width | 80-300mm |
制袋长度Bag making length | 100-1200mm |
制袋速度Bag making speed | 60-205只/分钟*2 |
最高线速度Max line speed of film | 115米/分钟m/min |
制袋厚度Bag making thickness | 0.005-0.02mm |
制袋形式Bag making methods | 连卷八折平口袋Rolling star sealing flat bag |
